Description:
BBR
- 2 consumers
- Throat: 213 mm
- Pitch size: 150 +- 12 mm
- Spray type fitting: WaterfallStream
- maximum flow rate at 3 bar: 22 l/min
- Flow for bath inlet at 3 bar: 22 l/min
- Flow rate for hand shower at 3 bar: 14.5 l/min
- Ceramic mixing system
- Temperature limit adjustable
- Pressure diverter Select with automatic reset
- Intrinsically safe against backflow DIN EN 1717
- with silencer
- suitable for instantaneous water heaters
- Connection size: DN15
- Connection type: S-connectors
- Wall mounting
- Min. operating pressure: 1 bar
- Max. operating pressure: 10 bar
